Дънна платка ASUS ROG MAXIMUS Z790 EXTREME MB LGA1700 4xDIMM DDR5 5xM.2 6xSATA 90MB1CB0-M0EAY0
изчерпано
Сокет: LGA 1700
Чипсет: Intel Z790
Тип на паметта: DDR5
Физически размер: Extended ATX
Слотове за памет: 4
Честота на паметта: 5600 MHz
Гаранция:
0.0
от 5.0
(0)
Купи и събери
14 точки
Плати по-лесно и сигурно с
Виж всички продукти на Asus
Пазарувай по марка
Характеристики
| Физически размер | Extended ATX |
| Чипсет | Intel Z790 |
| Сокет | LGA 1700 |
| Съвместими процесори | (supports 12th/13th and 14th Generation Intel Core / Pentium Gold / Celeron) |
| BIOS | UEFI BIOS, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode |
| Тип BIOS | AMI |
| Тип на паметта | DDR5 |
| Честота на паметта | 5600 MHz |
| ECC support | Non-ECC, on-die ECC |
| Memory Registered / Buffered | Unbuffered |
| Слотове за памет | 4 |
| Максимална памет | 192 GB |
| Брой процесорни гнезда | 1 |
| Дисков интерфейс | SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 5.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 4 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 |
| RAID | Intel Rapid Storage Technology |
| LAN порт | 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, Bluetooth 5.3, 802.11a/b/g/n/ac/ax (Wi-Fi 6E) |
| Звук | SupremeFX (ALC4082) |
| Звуков изход | HD Audio (8-channel) |
| Аудио стандарти | High Definition Audio, DTS Sound Unbound |
| Портове | 1 x HDMI 1 x Thunderbolt 4/DisplayPort/USB4 1 x USB-C 3.2 Gen2x2 1 x USB-C 3.2 Gen 2 7 x USB 3.2 Gen 2 2 x aerial 1 x LAN (10Gigabit Ethernet) 1 x LAN (2.5Gigabit Ethernet) 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x audio line-out (center/subwoofer) - mini-jack 1 x audio line-out (rear) - mini-jack 1 x audio line-in - mini-jack 1 x SPDIF out |
| Разширителни слотове | 1 x CPU 4 x DIMM 288-pin 1 x PCIe 5.0 x16 1 x PCIe 5.0 x16 (auto turn-off if M.2 is occupied) 1 x PCIe 4.0 x4 3 x M.2 socket (2230/2242/2260/2280/22110 M.2 Key M slot) 2 x M.2 socket (2280 M.2 Key M slot) |
| Вътрешен интерфейс | 1 x USB-C 3.2 Gen 2x2 - header 1 x Thunderbolt 4 - header 4 x USB 3.2 Gen 1 - header 4 x USB 2.0 - header 1 x audio - header |
| Wake on LAN | Wake on LAN (WOL), wake on PME |
| Функции | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
| Софтуер |
ROG CPU-Z ASUS AI Suite III ASUS Turbo App PC Cleaner WinRAR Sonic Studio Virtual Mixer ROG GameFirst VI MemTest86 ASUS AURA Creator AIDA64 Extreme (1 year licence) Sonic Suite Companion MyAsus ROG True Voltician Armoury Crate Sonic Studio III Sonic Radar III ASUS Fan Xpert 4 |
| Конектори за захранване | 24-pin main power connector, 2 x 8-pin ATX12V connectors, 6-pin PCI Express power connector |
| Включени кабели | 6 x Serial ATA cable |
| Аксесоари |
Thermal pad for M.2 SSD ROG logo plate sticker Q-Connector ROG key chain ASUS Wi-Fi moving aerial USB drive 1 to 3 ARGB LED splitter cable ROG Fan Controller 1 to 2 ARGB LED splitter cable 2 x 1 to 4 fan splitter cable 3 in 1 thermistor cables pack ROG True Voltician M.2 screw package ROG stickers ROG VIP card 4 ROG True Voltician cables ROG screwdriver ROG DIMM.2 with heatsink ARGB input cable USB input cable ROG Fan Controller hook-and-loop tape ROG DIMM.2 M.2 pad 2 ROG DIMM.2 M.2 screw packages DDR5 fan holder fan extension power cable |
| Ширина | 30.5 cm |
| Дълбочина | 27.7 cm |
| Други характеристики |
DualBIOS ASUS Q-Design Q-DIMM ASUS EZ DIY Q-LED Q-Slot ProbeIt ASUS Extreme Engine Digi+ CrashFree BIOS 3 ASUS Q-Connector Intel Turbo Boost Technology 2.0 ASUS TPU (TurboV Processing Unit) ASUS ROG Extreme OC Q-Code Preboot eXecution Environment (PXE) Clear CMOS Button LANGuard ASUS SafeSlot Intel Turbo Boost Technology 3.0 ASUS SafeDIMM M.2 heatsink Water Pump Header pre-mounted I/O shield ASUS Aura Sync MicroFine Alloy Chokes 10K Black Metallic Capacitors ASUS OptiMem III FlexKey button ASUS ProCool II M.2 Q-Latch ReTry button Start button PCIe Slot Q-Release CPU Socket lever protector Quick Charge 4+ ASUS 2" LiveDash OLED Safe boot button AniMe Matrix LED display VRM heatsink design BIOS FlashBack button 24+1+2 Phase Power Design metal backplate ASUS Enhanced Memory Profile (AEMP) II Slow Mode switch ROG Aura Sync backplate M.2 heatsink backplate |
| Гаранция | 36 месеца |
| Код на продукта | 90MB1CB0-M0EAY0 |
Виж повече
Допълнителна информация
- True performance
Limitless power allows you to make the most of the potential of Intel processors and DDR5 memory modules. - AI Overclocking
The tuning process is even faster and smarter than ever before. ASUS AI Overclocking performs CPU and cooling system profiling, allowing you to plan the optimal configuration and maximize your system's potential. The predicted optimal values can be activated automatically or used as a basis for further experimentation with settings. - Grouped power system architecture
The architectures of current processors place enormous demands on motherboard power supply systems. This is dictated by the immediate transition from maximum power saving mode to full load mode. The ROG VRM architecture addresses this challenge by using grouped power phases to rapidly change current while maintaining exemplary performance in terms of operating temperature. - DDR5
ROG has a long tradition of achieving the highest possible memory module speeds, and the DDR5 standard will be no exception. - VRM heatsink and aluminum I/O panel heatsink
The VRM heatsink on the MOSFET transistors and chokes is connected to the aluminum I/O socket panel heatsink via a built-in "U" shaped heat pipe, thus increasing the weight and surface area for heat dissipation. - M.2 heatsinks and backplates
Large heat sinks and backplates provide ample surface area for heat dissipation to keep installed M.2 drives cool. - High conductivity thermal pads
All thermal pads improve the overall heat dissipation properties of the system by transferring heat generated by the power stages to the heatsink. - Solid metal backplate
The electroplated metal backplate reinforces the frame structure of the ROG Maximus Z790 Extreme motherboard, preventing it from bending. - Chipset heat sink
A dedicated heatsink draws heat away from the chipset, helping to maintain ideal operating temperatures. - Multiple sources of temperature monitoring
Each slot can be set to monitor and respond to one of three user-configurable thermal sensors. - 4-pin fan slots
In addition to a pair of CPU fan slots, the Maximus Z790 Extreme motherboard is equipped with two chassis fan slots and two heatsink slots, each supporting automatic fan type detection - PWM or DC. - PCIe 5.0
The ROG Maximus Z790 Extreme motherboard offers extensive Gen 5 connectivity, which provides the maximum possible bandwidth for the fastest SSDs and graphics cards available. - Wi-Fi 6E
The built-in Wi-Fi card uses the 6 GHz band for lower transmission latency on networks with multiple simultaneously connected wireless devices, plus wide 160 MHz channels to speed up data transfers. For even smoother connections, the 5 or 6 GHz bands can be used simultaneously with the 2.4 GHz band for connections - thanks to Intel Double Connect Technology. - 10G Ethernet
Marvell AQtion's integrated 10Gbps network card is designed to meet the requirements of advanced users and content creators, enabling them to enter the next era of home network connections. With nearly unlimited bandwidth, file transfers and system backups are now faster than ever before.
Виж повече
Информация за производителя
| Контакт | [email protected] |
| Адрес | Asus Global PTE. LTD. 10 Changi Business Park Central 2 486030 Singapore, SG |
| Уебсайт | https://www.asus.com |
| Партньорска информация | PIC.bg е доверен партньор на Asus |
Виж повече
Ние от PIC.bg постоянно полагаме усилия информацията на тази страница да е точна. В редки случаи съдържанието може да е некоректно. Всички снимки са с информативна цел и е възможно да съдържат аксесоари, които не са включени в стандартния пакет. Някои от спецификациите или цените могат да бъдат променяни от производителя без предизвестие или да съдържат експлоатационни грешки. Всички промоции, посочени в сайта, се предлагат до изчерпаване на количествата.
