Storage(NAS) 12-bay Synology NAS Server for Small and Medium Business RS1221RP+

изчерпано

Изпрати запитване за наличност
12-bay Synology NAS Server for Small and Medium Business
Гаранция:
0.0 от 5.0 (0)
Bonus points loyalty badge
Купи и събери 33 точки
Програма за лоялност
Безплатна доставка
14 дни право
на връщане
Оторизиран сервиз
Плати по-лесно и сигурно с
Изчерпано
3 259 лв.
/
1 66630 €

Виж всички продукти на Synology

Пазарувай по марка
Характеристики
USB портове 2xUSB3.2
Други характеристики File/Mail/FTP/Print/DHCP/Directory/VPN/Syslog server, web station, Android/Windows phone app., VMware®
Мрежови портове surveillance station
Dimensions HxWxD RS1221+ : 88 mm x 482 mm x 306.6 mmRS1221RP+ : 88 mm x 482 mm x 407.5 mm
Тегло RS1221+ : 6.9 kgRS1221RP+ : 11.7 kg
Гаранция 36 месеца
Процесор Quad Core 2.2GHz AMD Ryzen CPU
CPU turbo boost 4-core 2.2 GHz
RAM-памет 4 GB DDR4 ECC SODIMM
Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Encryption AES-NI encryption
Мощност RS1221+ : 250 WRS1221RP+ : 350 W
Консумация RS1221+ : 49.89 W (Access) 22.64 W (HDD Hibernation)<br />RS1221RP+ : 61.94 W (Access) 29.98 W (HDD Hibernation)
Работна влажност 5% to 95% RH
Ниво на шум RS1221+ : 25.2 dB(A)RS1221RP+ : 40 dB(A)
CPU architecture 64-bit
Hot swappable drive Да
System fan 80 mm x 80 mm x 2 pcs
Power recovery Да
Работна температура 0°C to 35°C (32°F to 95°F)
Maximum users 1,800
Maximum connections 30
Scheduled power On / Off Да
Код на продукта RS1221RP+
Виж повече
Допълнителна информация

CPU

 CPU Model AMD Ryzen V1500B
CPU Architecture 64-bit
CPU Frequency 4-core 2.2 GHz
Hardware Encryption Engine (AES-NI) V

Memory

 System Memory 4 GB DDR4 ECC SODIMM
Memory Module Pre-installed 4 GB (4 GB x 1)
Total Memory Slots 2
Maximum Memory Capacity 32 GB (16 GB x 2)
Notes
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

 Drive Bays 8
Maximum Drive Bays with Expansion Unit 12 (RX418 x 1)
Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • 2.5" SATA SSD
Maximum Single Volume Size* 108 TB
Hot Swappable Drive V
Notes
  • Storage Pool and volume creation require all drives to be listed as compatible on the device model's compatibility list.
  • "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • Each internal volume (may consist of multiple drives) is expandable up to 108TB.

External Ports

 RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
USB 3.2 Gen 1 Port* 2
eSATA Port 1
Notes The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

PCIe

 PCIe Expansion 1 x Gen3 x8 slot (x4 link)

File System

 Internal Drives
  • Btrfs
  • EXT4
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
Notes exFAT Access is purchased separately in Package Center.

Appearance

 Form Factor (RU) 2U
Size (Height x Width x Depth) RS1221+ : 88 mm x 482 mm x 306.6 mmRS1221RP+ : 88 mm x 482 mm x 407.5 mm
Weight RS1221+ : 6.9 kgRS1221RP+ : 11.7 kg
Rack Installation Support* RS1221+ :
  • 2-post 19" rack (direct mounting)
  • 4-post 19" rack (Synology Rail Kit - RKM114/RKS1317)
RS1221RP+ : 4-post 19" rack (Synology Rail Kit - RKS1317)
Notes The rail kit is sold separately

Others

 System Fan 80 mm x 80 mm x 2 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Power Recovery V
Noise Level* RS1221+ : 25.2 dB(A)RS1221RP+ : 40 dB(A)
Scheduled Power On / Off V
Wake on LAN / WAN V
Power Supply Unit / Adapter RS1221+ : 250 WRS1221RP+ : 350 W
Redundant Power Supply RS1221RP+
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* RS1221+ : 49.89 W (Access) 22.64 W (HDD Hibernation)
RS1221RP+ : 61.94 W (Access) 29.98 W (HDD Hibernation)
British Thermal Unit RS1221+ : 170.23 BTU/hr (Access) 77.25 BTU/hr (HDD Hibernation)
RS1221RP+ : 211.35 BTU/hr (Access) 102.30 BTU/hr (HDD Hibernation)
Notes
  • Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

 Operating Temperature 0°C to 35°C (32°F to 95°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH

Certification
  • FCC
  • CE
  • BSMI
  • EAC
  • CCC
  • KC
  • VCCI
  • RCM

Warranty

 3-year hardware warranty, extendable to 5-year coverage - EW202
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

 RoHS Compliant

Packaging Content

 RS1221+ :
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 1
  • C13 to C14 power cord x 1
  • Quick Installation Guide X 1
RS1221RP+ :
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 2
  • Quick Installation Guide X 1

Optional Accessories

 RS1221+ : RS1221RP+ :
Notes RS1221+ :
  • Certain items may not be available in your location. Please contact your local distributors for more information.
  • All memory modules will operate at the maximum frequency specified by the CPU manufacturer.
RS1221RP+ : All memory modules will operate at the maximum frequency specified by the CPU manufacturer.

DSM Specifications

Storage Management

 Maximum Internal Volume Number 64
SSD Read / Write Cache (White Paper) V
SSD TRIM V
Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
Volume Expansion by Adding a HDD
  • Synology Hybrid RAID
  • JBOD
  • RAID 5
  • RAID 6
Global Hot Spare Supported RAID Type
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10

File Services

 File Protocol CIFS/AFP/NFS/FTP/WebDAV
Maximum Concurrent CIFS/AFP/FTP Connections 1,000
Maximum Concurrent CIFS/AFP/FTP Connections (with RAM expansion) 2,000
Windows Access Control List (ACL) Integration V
NFS Kerberos Authentication V
Notes
  • Regarding data concerning tests with RAM expansion, all memory slots are installed with the maximum capacity of supported RAM.
  • The testing standard was based on the maximum number of concurrent connections supported by this model. During the testing, 25% of the connections were used to transfer files concurrently. The transfer process guaranteed that the connections were not interrupted; the minimum transfer speed was not guaranteed.

Account & Shared Folder

 Maximum Local User Accounts 2,048
Maximum Local Groups 256
Maximum Shared Folder 512
Maximum Shared Folder Sync Tasks 16

High Availability

 Synology High Availability V

Log Center

 Syslog Events per Second 800

Virtualization

 VMware vSphere with VAAI V
Windows Server 2016 V
Windows Server 2019 V
Citrix Ready V
OpenStack VV

General Specifications

 Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers
  • Google Chrome
  • Firefox
  • Microsoft Edge
  • Internet Explorer 10 onwards
  • Safari 10 onwards
  • Safari (iOS 10 onwards)
  • Google Chrome (Android 6.0 onwards)
Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文

Add-on Packages view the complete package list

Antivirus by McAfee (Trial)

 V

Central Management System

 V

Synology Chat

 Maximum Users 1,500
Notes
  • The number of concurrent HTTP connections for Synology Chat was configured to the maximum.
  • For tested models with expandable memory, the maximum amount of RAM was installed.

Document Viewer

Download Station

 Maximum Concurrent Download Tasks 80

exFAT Access (Optional)

 V

iSCSI Manager

 Maximum iSCSI Target Number 128
Maximum iSCSI LUN 256
iSCSI LUN Clone/Snapshot, Windows ODX

Synology MailPlus / MailPlus Server

 Free Email Accounts 5 (Licenses required for additional accounts)
Maximum Number of Concurrent Users 150
Maximum Server Performance 1,484,000 emails per day, approx. 45GB
Notes
  • Models with more than 4 bays were installed with two SSDs for SSD cache.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers.
  • Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only).

Media Server

 DLNA Compliance V

Moments

 Facial Recognition V
Subject Recognition V
Auto Color & Rotate V
Moments Select V

Snapshot Replication

 Maximum Snapshots per Shared Folder 1,024
Maximum of System Snapshots 65,536

Surveillance Station

 Maximum IP cam (Licenses required) 40 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264) 1200 FPS @ 720p (1280x720)
1050 FPS @ 1080p (1920x1080)
600 FPS @ 3M (2048x1536)
440 FPS @ 5M (2591x1944)
320 FPS @ 4K (3840x2160)
Total FPS (H.265) 1200 FPS @ 720p (1280x720)
1200 FPS @ 1080p (1920x1080)
1120 FPS @ 3M (2048x1536)
600 FPS @ 5M (2591x1944)
480 FPS @ 4K (3840x2160)
Notes
  • Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
  • The maximum channel number also includes devices installed on Virtual DSM.
  • Total FPS may be affected by other services running at the same time (e.g., archive tasks performed by Archive Vault).

Synology Drive

 Recommended Number of Hosted Files 1,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Recommended Number of Concurrent Sync Clients 550 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Notes
  • Exceeding the recommended numbers above will not block application operations, but may result in longer response time.
  • Utilizing SSD cache can significantly improve performance.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.

Synology Office

 Maximum Users 1,800
Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM

Video Station

 V

Virtual Machine Manager

 Recommended Virtual Machine Instances 8 (Learn more)
Recommended Virtual DSM Number (Licenses required) 8 (including 1 Free License)
Notes The specifications vary depending on system configuration and memory size.

VPN Server

 Maximum Connections 30
