Storage(NAS) Synology DS223j DS223J

Synology DS223j
Гаранция:
0.0 от 5.0 (0)
Bonus points loyalty badge
Купи и събери 5 точки
Програма за лоялност
Безплатна доставка
14 дни право
на връщане
Оторизиран сервиз
Плати по-лесно и сигурно с
на склад
429 лв.
/
21934 €

Виж всички продукти на Synology

Пазарувай по марка
Характеристики
USB портове 2x USB3.2
Мрежови портове 1x Gb LAN
Dimensions HxWxD 165 mm x 100 mm x 225.5 mm
Тегло 0.88 kg
Гаранция 24 месеца
Тип Външен
Височина 165 мм
Ширина 100 мм
Дълбочина 225.5 мм
Физически размер Tower
Процесор 7GHz quad core Realtek RTD1619B
CPU turbo boost 4-core 1.7 GHz
CPU slots 1
RAM-памет 1 GB DDR4 non-ECC
Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Интерфейс
LAN: 1x Gigabit Ethernet/Fast Ethernet/Ethernet (RJ-45)

USB 3.2 Gen 1: 2x (USB 3.2 (type A))
Аксесоари
Захранващ адаптер

Ръководство за употреба
Мощност 60 W
Консумация 16.31 W (Access)<br />4 W (HDD Hibernation)
Работна влажност 5% to 95% RH
Ниво на шум 18.2 dB(A)
Цвят Бял
CPU architecture 64-bit
Hardware encryption engine V
System fan 92 mm x 92 mm x 1 pcs
Power recovery Не
Работна температура 0°C to 40°C (32°F to 104°F)
Maximum users 200
Maximum connections 10
Scheduled power On / Off Да
Код на продукта DS223J
Виж повече
Допълнителна информация
CPU
 CPU Model Realtek RTD1619B
CPU Quantity 1
CPU Architecture 64-bit
CPU Frequency 4-core 1.7 GHz
Hardware Encryption Engine V
Memory
 System Memory 1 GB DDR4 non-ECC
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
 Drive Bays 2
Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA SSD (with optional 2.5" Disk Holder)
Hot Swappable Drive* -
Notes "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
 RJ-45 1GbE LAN Port* 1
USB 3.2 Gen 1 Port* 2
Notes
  • This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
  • The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
File System
 Internal Drives
  • Btrfs
  • EXT4
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT
Notes Btrfs file system is available from DSM 7.2-64570.
Appearance
 Size (Height x Width x Depth) 165 mm x 100 mm x 225.5 mm
Weight 0.88 kg
Others
 System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
  • Low-power Mode
Brightness Adjustable Front LED Indicators V
Power Recovery V
Noise Level* 18.2 dB(A)
Scheduled Power On / Off V
Wake on LAN / WAN V
Power Supply Unit / Adapter 60 W
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption 16.31 W (Access)
4 W (HDD Hibernation)
British Thermal Unit 55.62 BTU/hr (Access)
13.64 BTU/hr (HDD Hibernation)
Notes
  • For more information on how power consumption is measured, refer to this article.
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
 Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
Warranty
 2-year hardware warranty, extendable to 4 years with Extended Warranty Plus
Notes
  • Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions.
  • The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
 RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 1
  • Quick Installation Guide X 1
Optional Accessories
  • 3.5" SATA HDD: HAT3300
  • Surveillance Device License Pack
  • Disk Holder: Type C
DSM Specifications
Storage Management
 Maximum Single Volume Size* 108 TB
Maximum Internal Volume Number 64
Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
RAID Migration Basic to RAID 1
Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
Volume Expansion by Adding a HDD Synology Hybrid RAID
Notes
  • Usable capacity for each volume will be lower than the maximum volume size and is dependent on the filesystem and the amount of system metadata stored.
  • Actual maximum storage pool and volume sizes depend on drive sizes used, the number of drive bays available, and the RAID configuration.
File Services
 File Protocol SMB/AFP/NFS/FTP/WebDAV
Maximum Concurrent SMB/AFP/FTP Connections 100
Windows Access Control List (ACL) Integration V
NFS Kerberos Authentication V
Notes The testing standard was based on the maximum number of concurrent connections supported by this model. During the testing, 25% of the connections were used to transfer files concurrently. The transfer process guaranteed that the connections were not interrupted; the minimum transfer speed was not guaranteed.
Account & Shared Folder
 Maximum Local User Accounts 1,024
Maximum Local Groups 256
Maximum Shared Folder 256
Maximum Shared Folder Sync Tasks 4
Hyper Backup
 Data & Folder Backup V
Log Center
 Syslog Events per Second 200
General Specifications
 Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers
  • Google Chrome
  • Firefox
  • Microsoft Edge
  • Safari
Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
Notes For an updated list of supported browser versions, check the DSM Technical Specifications.
Add-on Packages view the complete package list
Synology Chat
 V
Download Station
 Maximum Concurrent Download Tasks 80
SAN Manager
 Maximum iSCSI Target Number 10
Maximum LUN 10
LUN Clone/Snapshot, Windows ODX V
Media Server
 DLNA Compliance V
Synology Photos
 Facial Recognition V
Snapshot Replication
 Maximum Snapshots per Shared Folder 256
Maximum of System Snapshots 4,096
Notes Snapshot Replication is available from DSM 7.2-64570.
Surveillance Station
 Maximum IP cam (Licenses required) 12 (including 2 Free License) (see all supported IP cameras)
Total FPS (H.264) 360 FPS @ 720p (1280x720)
360 FPS @ 1080p (1920x1080)
300 FPS @ 3M (2048x1536)
150 FPS @ 5M (2591x1944)
110 FPS @ 4K (3840x2160)
Total FPS (H.265) 360 FPS @ 720p (1280x720)
360 FPS @ 1080p (1920x1080)
360 FPS @ 3M (2048x1536)
350 FPS @ 5M (2591x1944)
200 FPS @ 4K (3840x2160)
Notes
  • Maximum IP cameras and FPS figures are tested with the device fully populated with drives and under a continuous recording setup.
  • Actual system capabilities may differ depending on system configuration, drive performance, number of features enabled, and if additional workloads are present.
Synology Drive
 Recommended Number of Concurrent Sync Clients 200 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Recommended Number of Hosted Files 500,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Notes
  • Exceeding the recommended numbers above will not block application operations, but may result in longer response time.
  • Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.
Synology Office
 Maximum Users 200
Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Video Station
 V
VPN Server
 Maximum Connections 10
Виж повече
Информация за производителя
Контакт +49 211 9666 9666
Адрес Synology GmbH Grafenberger Allee 295 40237 Düsseldorf Deutschland
Уебсайт https://www.synology.com/en-global
Виж повече

Ние от PIC.bg постоянно полагаме усилия информацията на тази страница да е точна. В редки случаи съдържанието може да е некоректно. Всички снимки са с информативна цел и е възможно да съдържат аксесоари, които не са включени в стандартния пакет. Някои от спецификациите или цените могат да бъдат променяни от производителя без предизвестие или да съдържат експлоатационни грешки. Всички промоции, посочени в сайта, се предлагат до изчерпаване на количествата.
